Magnetic AutoControl ACCPRO-H-LC01240 Left-Hand Barrier Gate w/ 12' MicroBoom Arm (White)

Overview

The Magnetic AutoControl ACCPRO-H-LC01240 is a left-handed barrier gate opener built with a taller cabinet that provides extra room for accessories. An optional barrier arm skirt (with or without climb-over prevention) can be added to help stop intruders from crawling under or climbing over the barrier. Designed and manufactured by Magnetic AutoControl, the ACCPRO-H-LC01240 includes a 12 ft MicroBoom, a white powder-coated aluminum housing, and the MGC Pro controller — an EN 13849 compliant control unit with an LCD display. The MHTM MicroDrive maintenance-free motor combines the motor, motor control, and gearing into one compact drive unit, delivering high torque for reliable operation in severe weather conditions.

Key Features

• 4.0-second open and close speeds
• Rated for 10 million opening and closing cycles
• MHTM MicroDrive maintenance-free motor
• MGC Pro controller with LCD display
• Integrated dual-channel loop detector
• Selectable opening and closing times
• Optional boom skirt available (sold separately)
• Maximum power consumption of 25W
• White powder-coated aluminum housing
• 2-year warranty
• UL & CSA certified
• Protection class: IP 54

Specifications

• Model: ACCPRO-H-LC01240
• Barrier Width: Maximum 12 ft (3.6 m)
• Opening/Closing Time: 4.0 seconds
• Cycle Rating: 10 million cycles
• Max Power Consumption: 25 W
• Input Voltage: 110/115/120 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase)
• Frequency: 50 / 60 Hz
• Temperature Range: -22°F to +122°F
• Protection Class: IP 54
• Dimensions (W x D x H): 12" x 14" x 44"
• Weight (without boom): 97 lbs
• Color: White
• Certifications: UL & CSA
