Magnetic AutoControl ACCPRO-H-LC01540 Left-Hand Barrier Gate w/ 15' MicroBoom Arm (White)

Overview

The Magnetic AutoControl ACCPRO-H-LC01540 is a heavy-duty barrier gate opener built with a taller cabinet that provides extra room for accessories. An optional barrier arm skirt (with or without climb-over prevention) can be added to help stop intruders from crawling under or climbing over the barrier. This unit ships with a 15 ft straight MicroBoom in a white powder-coated aluminum housing and is manufactured by Magnetic AutoControl, a leading name in the barrier gate industry.

Key Features

• Designed and features a taller cabinet with room for accessories — optional boom skirt available (sold separately); a pendulum support or support post is required when a skirt is used
• 4.0-second open and close speeds
• Selectable opening and closing times
• MHTM MicroDrive maintenance-free motor with high torque for reliable operation in severe weather conditions — motor, motor control, and gearing combined in one compact drive unit
• MGC Pro controller with LCD display, EN 13849 compliant
• Integrated dual-channel loop detector
• Rated for 10 million opening and closing cycles
• Maximum power consumption of 25W
• IP 54 protection class
• UL & CSA certified
• 2-year warranty

Specifications

• Model: ACCPRO-H-LC01540
• Barrier Width: Maximum 15 ft (4.5 m)
• Opening/Closing Time: 4.0 seconds
• Cycle Rating: 10 million cycles
• Max Power Consumption: 25 W
• Input Voltage: 110/115/120 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 3 Phase); 220/230/240 AC (60 Hz, 1 Phase); 230 AC (50 Hz, 1 Phase)
• Frequency: 50 / 60 Hz
• Temperature Range: -22°F to +122°F
• Protection Class: IP 54
• Dimensions (W x D x H): 12" x 14" x 44"
• Weight (without boom): 97 lbs
• Housing: White powder-coated aluminum
• Boom Length: 15 ft (included)
• Certifications: UL & CSA
