Magnetic AutoControl ACCPRO-H-RC01240 Right-Hand Barrier Gate w/ 12' MicroBoom Arm (White)
The Magnetic AutoControl ACCPRO-H-RC01240 is a right-handed barrier gate opener designed for boom skirt applications, featuring a 12 ft MicroBoom and 4.0-second open/close speed rated for 10 million cycles.
Overview
The Magnetic AutoControl ACCPRO-H-RC01240 is a white powder-coated aluminum barrier gate opener built with a taller cabinet that provides extra room for accessories. An optional barrier arm skirt (with or without climb-over prevention) can be added to help stop intruders from crawling under or climbing over the barrier. Designed and manufactured by Magnetic AutoControl, this unit includes a 12 ft MicroBoom, an MGC Pro controller with LCD display, and an integrated dual-channel loop detector — all housed in a compact, durable enclosure.
Key Features
- 4.0-second open and close speeds with selectable opening and closing times
- MHTM MicroDrive maintenance-free motor with high torque for reliable operation in severe weather conditions — motor, motor control, and gearing combined in one compact drive unit
- MGC Pro controller with LCD display; EN 13849 compliant and easy to configure
- Integrated dual-channel loop detector included
- Optional boom skirt can be added
- Rated for 10 million opening and closing cycles
- White powder-coated aluminum housing
- Maximum power consumption of 25W
- 2-year warranty
- UL & CSA certified
Specifications
- Model: ACCPRO-H-RC01240
- Barrier Width: Maximum 12 ft (3.6 m)
- Boom Length: 12 ft (straight boom)
- Opening/Closing Time: 4.0 seconds
- Cycle Rating: 10 million cycles
- Dimensions (W x D x H): 12" x 14" x 44"
- Weight (without boom): 97 lbs
- Input Voltage: 110/115/120 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 3 Phase); 220/230/240 AC (60 Hz, 1 Phase); 230 AC (50 Hz, 1 Phase)
- Max Power Consumption: 25 W
- Frequency: 50 / 60 Hz
- Protection Class: IP 54
- Temperature Range: -22°F to +122°F
- Color: White
- Certification: UL & CSA
Please Note: Boom skirt sold separately. A pendulum support or support post is required when using a boom skirt.
Order the Magnetic AutoControl ACCPRO-H-RC01240 today for a reliable, high-cycle barrier gate solution built for demanding access control environments.
