Magnetic AutoControl ACCPRO-H-RC02040 Right-Hand Barrier Gate w/ 20' MicroBoom Arm (White)

Overview

The Magnetic AutoControl ACCPRO-H-RC02040 is a white powder-coated aluminum barrier gate opener built with a taller cabinet that provides extra room for accessories. An optional barrier arm skirt (with or without climb-over prevention) can be added to help stop intruders from crawling under or climbing over the barrier. This unit includes a 20 ft MicroBoom and is rated for an exceptional 10 million opening and closing cycles, backed by a 2-year warranty.

Key Features

• MHTM MicroDrive maintenance-free motor — combines motor, motor control, and gearing in one compact drive unit for reliable operation in severe weather conditions
• MGC Pro controller with LCD display, EN 13849 compliant and easy to configure
• Integrated dual-channel loop detector included
• 4.0-second open and close speeds
• Selectable opening and closing times
• Optional boom skirt can be added
• Maximum power consumption of 25W
• White powder-coated aluminum housing
• Rated for 10 million cycles
• 2-year warranty

Specifications

• Model: ACCPRO-H-RC02040
• Barrier Width: Maximum 20 ft (6.0 m)
• Opening/Closing Time: 4.0 seconds
• Cycle Rating: 10 million cycles
• Dimensions (W x D x H): 12" x 14" x 44"
• Weight (without boom): 97 lbs
• Input Voltage: 110/115/120 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 1 Phase), 208 AC (60 Hz, 3 Phase), 220/230/240 AC (60 Hz, 1 Phase), 230 AC (50 Hz, 1 Phase)
• Max Power Consumption: 25W
• Frequency: 50 / 60 Hz
• Protection Class: IP 54
• Temperature Range: -22°F to +122°F
• Certifications: UL & CSA
• Color: White
• Alternate Part Number: Access Pro-H-LC02040

Includes

• MGC Pro Controller with LCD display
• 20 ft MicroBoom
• Integrated dual-channel loop detector
• White powder-coated aluminum housing

Please Note: Booms over 15 ft must use a pendulum support or support post. Boom skirt is sold separately. A pendulum support or support post is required when using a boom skirt.

Order the Magnetic AutoControl ACCPRO-H-RC02040 today for a high-cycle, low-maintenance barrier gate solution built for demanding access control.
