Magnetic AutoControl ACCPRO-L-RC02040 Right-Hand Barrier Gate w/ 20' VarioBoom Arm (White)
The Magnetic AutoControl ACCPRO-L-RC02040 is a right-handed barrier gate opener featuring a 20 ft VarioBoom and 4.0-second open/close speeds in a white powder-coated aluminum housing.
Overview
The Magnetic AutoControl ACCPRO-L-RC02040 is engineered to control access across extra-wide lanes, making it well suited for industrial sites, residential buildings, and small parking areas. The unit ships with a 20 ft VarioBoom — a barrier arm with a foam edge designed to protect people from contact. Powering the system is the MHTM MicroDrive, a maintenance-free drive unit that combines the motor, motor control, and gearing in one compact assembly for reliable operation in severe weather conditions. The integrated MGC Pro controller provides an LCD display, programmable I/O, a selectable auto-open on power failure feature, and adjustable open/close speeds. The controller is EN 13849 compliant.
Key Features
- 4.0-second open and close speeds
- Adjustable opening and closing times
- MHTM MicroDrive maintenance-free motor
- MGC Pro controller with LCD display and programmable I/O
- Integrated dual-channel loop detector
- Selectable auto-open on power failure
- 20 ft VarioBoom with foam protective edge
- White powder-coated aluminum housing
- Rated for 10 million opening and closing cycles
- Maximum power consumption of 25W
- UL & CSA certified
- 2-year warranty
- Please Note: Gates with booms over 15 ft must use a pendulum support or support post.
Specifications
- Model: ACCPRO-L-RC02040
- Included Arm Length: 20 ft
- Open/Close Speed: 4.0 seconds
- Cycle Rating: 10 million cycles
- Max Power Consumption: 25 W
- Input Voltage: 110/115/120 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 1 Phase); 208 AC (60 Hz, 3 Phase); 220/230/240 AC (60 Hz, 1 Phase); 230 AC (50 Hz, 1 Phase)
- Frequency: 50 / 60 Hz
- Protection Class: IP 54
- Temperature Range: -22°F to +122°F
- Dimensions (W x D x H): 12" x 14" x 36"
- Weight (without boom): 88 lbs
- Color: White
- Certifications: UL & CSA, EN 13849
- Alternate Part Number: Access Pro-L-LC02040
What's Included
- MGC Pro Controller
- 20 ft VarioBoom Barrier Boom
Order the Magnetic AutoControl ACCPRO-L-RC02040 today for a high-cycle, wide-lane barrier gate solution built to perform in demanding conditions.
