Linear DNT00026 1-Channel Key Ring Transmitter

Linear MINI-T 1-Channel Key Ring Transmitter

The Linear MINI-T (DNT00026) is a Delta-3 series key ring transmitter built for portable, single-channel wireless access control. Housed in a black plastic case with a single white activation button, it transmits at 310 MHz and pairs exclusively with Linear Delta-3 series receivers. The unit ships ready to use with a key ring and 12V battery included.

Key Features

• 1-channel operation — activates a single Linear Delta-3 compatible receiver
• 256 manually selectable codes via internal DIP switches
• Red LED indicator — confirms button press and battery status
• 310 MHz transmission frequency
• Key ring included for convenient attachment
• 12V A23 battery included — ready to operate out of the box
• FCC Part 15 certified

Specifications

• Model: MINI-T — DNT00026
• Format: Delta-3 (DIP switch)
• Channels: 1
• Frequency: 310 MHz
• Number of Codes: 256 manually selectable
• Dimensions: 2.2" L × 1.42" W × 0.66" D
• Color: Black case, white button
• Power: 12V (A23 type, included)

Compatibility

• Compatible with all Linear Delta-3 series receivers

The Linear MINI-T DNT00026 delivers straightforward, manual-code remote control in a compact, portable form factor suited for single-channel access control applications.
