MMTC 1MHD Mushroom Head Control
SKU
mmtc-1mhd
The MMTC 1MHD is a heavy duty mushroom head control featuring a large red push button in a NEMA 3R, 4, and 12-rated surface-mount enclosure with double pole, momentary contact operation.
Overview
The MMTC 1MHD Heavy Duty Mushroom Head Control delivers straightforward, reliable push-button control for gate systems. Its large red mushroom-style button is housed in a NEMA 3R, 4, and 12-rated enclosure built to withstand exterior conditions, while double pole contacts make wiring and installation straightforward.
Key Features
- Large Red Push Button — highly visible and easy to operate
- NEMA 3R, 4, and 12-Rated enclosure for exterior use and tamperproof protection
- Surface Mounted installation
- Heavy Duty Construction
- Double Pole Contacts — simplifies wiring
- Momentary Contact operation
- Normally Open and Normally Closed configurations supported
Specifications
- Contact Type: Momentary Contact, Double Pole
- Contact Configurations: Normally Open, Normally Closed
- Button Rating: 3 amp @ 240V AC
- Dimensions: 3 1/2" (H) x 3" (W) x 3" (D)
- Mount Type: Surface Mount
- Enclosure Rating: NEMA 3R, 4, and 12
- Part Number: 1MHD
The MMTC 1MHD is a dependable, weather-resistant control solution built for demanding exterior access control applications.
