Transmitter Solutions RECSYNPROX Wiegand Mobile Credential M

Overview

The Transmitter Solutions RECSYNPROX is a module and controller designed to retrofit or integrate into new installations, adding Bluetooth mobile credential capability to any existing Wiegand or stand-alone access control system. Credential management is handled through a cloud-based platform.

Key Features

• Compatible with any Wiegand bit format
• Operates in Wiegand mode or stand-alone mode
• Cloud-based credential management
• Supports dual authentication with card + pin mode
• AES128 encryption via mobile application
• Suitable for retrofit or new installs

Wiring

• Red — 8–24 VDC
• Black — GND
• Green — Wiegand D0 / Relay 1
• Yellow — Wiegand D0 Pullup (optional if not provided by reader or panel)
• White — Wiegand D1 / Relay 2
• Violet — Wiegand D1 Pullup (optional if not provided by reader or panel)
• Brown — RS-485 A
• Orange — RS-485 B
• Blue — RS-485 Termination (optional with SynQ if not provided by reader)

Specifications

• Encryption: AES128
• Working Environment: -40°C to +85°C
• Dimensions: 1.4 in x 1.2 in
• Compatible with: Any Wiegand bit format

Compatibility

The RECSYNPROX works with any Wiegand device or stand-alone system, making any existing access control setup mobile credential friendly.

The Transmitter Solutions RECSYNPROX is a straightforward solution for adding mobile credential capability to virtually any access control installation.
