Overview

The Transmitter Solutions DOLXFD1000BM is a zinc-alloy mullion keypad and card reader built for both indoor and outdoor environments. It operates as an outdoor backlit keypad reader, a fully-featured standalone controller, or a standalone keypad — offering flexible deployment to meet a range of access control requirements.

Key Features

• Mullion mount form factor
• Indoor or outdoor rated (IP66, -40°F to 140°F)
• Stand-alone or Wiegand operation
• Stand-alone mode supports up to 1,000 users (998 common, 2 panic)
• PIN length: 4–6 digits
• Built-in relay with latch or pulse mode
• HID 26-Bit & EM card compatibility
• Backlit keypad

Specifications

• User Capacity: 1,000 (998 common, 2 panic)
• Operating Voltage: 12–28 VAC/DC
• Power Consumption: 20mA standby / 30mA relay active
• Radio Technology: 125KHz Proximity
• Card Read Range: 2–6 cm
• Relay: 1 (NO, NC, Common)
• Adjustable Relay Output Time: 0–99 seconds
• Wiegand Interface: Wiegand 26–37 bits
• Operating Temperature: -40°F to 140°F
• Material: Zinc-alloy
• Dimensions: 5-1/4" x 2-1/8" x 7/8"
• Weight: 340g
• IP Rating: IP66

Compatibility

• HID 26-Bit compatible
• EM card compatible
• Wiegand 26–37 bit interface

The Transmitter Solutions DOLXFD1000BM delivers a rugged, multi-mode access control solution in a compact mullion form factor.
