Transmitter Solutions DOLCSAW1000H Mullion Stand-Alone Card

Overview

The Transmitter Solutions DOLCSAW1000H is a mullion-style stand-alone access control card reader designed to operate independently without a separate controller. It supports up to 1,000 users, features a built-in relay, and accepts both HID® and EM proximity cards. The slim ABS shell housing carries an IP66 (NEMA 4) waterproof rating and operates across a wide temperature range.

Key Features

• 1,000-user memory (998 common users)
• Built-in relay — NO, NC, and Common outputs
• Pulse or toggle relay mode
• Block or individual card programming and deleting
• Compatible with HID® and/or EM proximity cards
• IP66 (NEMA 4) waterproof rated housing
• Integrated alarm and buzzer
• Includes remote and add/delete manager cards
• Operates on 12 or 24V DC

Specifications

• User Capacity: 1,000 (998 common users)
• IP Rating: IP66 (NEMA 4)
• Relay: One (NO, NC, Common)
• Temperature Rating: -40°F to 140°F
• Proximity Card Reader: EM & HID®
• Read Range: 2–6 cm
• Operating Voltage: 12–24V DC
• Dimensions: 4-3/4"(L) x 1-7/8"(W) x 3/4"(D) inches
• Weight: 5-3/4 oz
• Housing: ABS Shell

The Transmitter Solutions DOLCSAW1000H delivers reliable stand-alone access control in a compact, weather-resistant mullion form factor.
