Linear MCS109950 1-Channel Coax Receiver

Overview

The Linear MCS109950 is a single-channel coax gate receiver designed for gate operator systems. It supports selectable 300 MHz or 310 MHz frequency operation and accepts 12–24V AC or DC power. The unit includes an 11-inch wire whip antenna, 3 feet of coax cable, and a bulkhead connector for remote antenna mounting in shielded enclosures.

Key Features

• Dual Frequency: Jumper-selectable 300 MHz or 310 MHz
• 1-Channel Operation
• Power: 12–24V AC or DC
• Code Security: 10-position dip switch with up to 1,024 programmable codes
• Relay Output: Normally open, rated up to 1 amp @ 30 VAC
• Antenna: 11-inch wire whip antenna included
• Coax Cable: 3 feet with bulkhead connector for remote antenna mounting
• Mounting: Surface mounted
• Material: Plastic
• UL/ETL Certified: Yes

Specifications

• Model: MCS109950
• Brand: Linear
• Frequency: 300 MHz or 310 MHz (jumper selectable)
• Channels: 1
• Power Supply: 12–24V AC/DC
• Code Range: Up to 1,024 codes (set by dip switches)
• Relay Output: Normally open, up to 1 amp @ 30 VAC
• Dimensions: 3.625" W x 5.25" H x 1.5" D
• Material: Plastic
• UL/ETL Certification: Yes
• Detection Type: RF – Radio Frequency
• Mounting Type: Surface Mounted
• Rated for: Indoor Usage

Compatibility

• Compatible with Multi-Code and Stanley Multi-Code transmitters operating at 300 MHz or 310 MHz

The Linear MCS109950 delivers dependable single-channel RF reception for professional gate operator installations.
