AES MULTI-CLASSIC-US Cellular Telephone Entry System
The AES MULTI-CLASSIC-US is a cellular telephone entry system supporting up to 500 apartments from a single SIM card, with HD voice via VoLTE, built-in prox reader, and remote management through the AES Cloud Portal.
Overview
The AES MULTI-CLASSIC-US (Multicom Classic) is a cellular telephone entry system designed for apartments and gated communities. It connects visitors to up to 500 apartments from a single SIM card, allowing 3 users per apartment. Visitors can scroll for residents or enter an apartment number to call. HD voice with VoLTE is supported where the correct APN is set and a VoLTE-enabled device is in use. The system is programmable via the AES PRO APP and works with the multi-network AESIM.
Key Features
- Calls up to 500 apartments from a single SIM card (3 users per apartment)
- HD voice with VoLTE (requires correct APN and VoLTE-enabled device)
- Prox reader included as standard
- Built-in time clock for automatic opening and closing of gates, barriers, or doors
- Do Not Disturb feature
- Remote programming and management via the AES Cloud Portal
- Programmable with the AES PRO APP
- Works with the multi-network AESIM
- Available in imperial or pedestal panel configurations
- Each kit includes: speech panel, power supply, install manual, SIM card options, antenna, and prox cards/tags
- Pedestal options: full black panel with blue lighting, or full steel panel with white lighting
Specifications
- Dial-Out Numbers per Apartment: 3 per apartment (1,500 total)
- Keypad Codes per Apartment (6-digit): 1 per apartment (500 total)
- Prox Cards/Tags per Apartment: 3 per apartment (1,500 total)
- Automatic Trigger Events per Week: 10
- Relays: 2
- Relay Type: N/C and N/O
- Relay Load: 2 amps, 24V AC max
- Power Consumption: 310mA on dial out, 2A peak demand
- Power Supply: 24V DC (24V DC 2A adaptor included)
- Modem Models: 4G EU, 4G USA, 4G AUS/NZ
- Visitor Codes/Cards — Permanent: 250
- Visitor Codes/Cards — Time-restricted: 250
- Visitor Codes/Cards — Temporary: 50
- Visitor Access Methods: Prox Cards, Keypad Codes (4 digits), Caller ID
Compatibility
- Works with the AES PRO APP for programming
- Compatible with the multi-network AESIM
- Managed remotely via the AES Cloud Portal
The AES MULTI-CLASSIC-US delivers flexible, cellular-based access control for apartments and gated communities with robust visitor management and remote administration capability.
