EMX Industries 2550-1 Multi-Voltage Vehicle Detector
The EMX Industries 2550-1 MVP-D-TEK is a multi-voltage vehicle detector accepting 12VDC to 240VAC, featuring dual relays and 10 sensitivity settings — one unit covers virtually any installation.
Overview
The EMX Industries 2550-1 MVP-D-TEK eliminates the guesswork of stocking multiple loop detectors. Its universal 12VDC to 240VAC power input means a single unit is ready for virtually any service call or new installation. Housed in an extruded anodized aluminum enclosure with an aluminum RF shield, the 2550-1 delivers reliable vehicle presence detection with built-in diagnostics and enhanced surge protection.
Key Features
- Multi-voltage power: 12 to 220 VAC/DC
- Dual relay outputs: presence & pulse or presence (1 Amp 30 VDC)
- Operates in both fail safe and fail secure modes
- 10 sensitivity settings
- Enhanced lightning/surge immunity
- Aluminum RF shield housing
- Built-in loop conditioner
- Loop isolation transformer
- Loop diagnostics
- Frequency counter
- Gold plated control contacts
- Automatic tuning on reset or power up
- Automatic tracking for environmental changes
Specifications
- Power Supply: 12VDC to 240VAC
- Current Consumption: 19.2mA @ 9VDC, 18.8mA @ 12VAC/DC, 17.3mA @ 24VAC, 9.5mA @ 24VDC, 13.5mA @ 115VAC, 11.0mA @ 237VAC
- Operating Temperature: -40°F to +180°F
- Surge Protection: Zener Diode / MOV
- Output Relays (2): 1 Amp 30 VDC
- Loop Input: Transformer isolation, lightning and transient protection
- Loop Inductance Range: 20 – 2000 uH, Q-factor of 5 or higher
- Tuning: Automatic on reset or power up
- Tracking: Automatic for environmental changes
- Height: 3.25" (83mm)
- Width: 2.56" (40mm)
- Length: 3.65" (90mm)
- Housing: Extruded Anodized Aluminum
- Connector: 86CP11 11 pin male
Compatible Accessories
- HAR-11 — 11 position harness, 3 feet of wire
- LD-11 — Black, wide profile, 11 pin socket base for DIN rail mount
- LD-11B — Black, narrow profile, 11 pin socket base for DIN rail mount
- PR-LOOP — Preformed loop available in 2x6, 4x6, 4x8, 4x10, 6x10, or 8x12 ft with 50 ft lead
- TSTL — Test loop, 1.25 x 1.25 x 0.75 inches
The EMX Industries 2550-1 MVP-D-TEK is the single-unit solution that simplifies inventory, reduces service call uncertainty, and delivers dependable vehicle detection across a wide range of installations.
