MMTC 3BXLT Exterior Three-Button Control Station

Overview

The MMTC 3BXLT is an exterior-rated control station designed for gates, industrial machinery, and automation systems. It provides Open, Close, and Stop control combined with a keyed lockout (On-Off) switch for added access security. Its non-metallic enclosure carries NEMA 3R, 4, and 12 ratings, making it suitable for demanding outdoor and industrial environments. The 3BXLT is both UL Listed and CSA Approved.

Key Features

• Keyed Lockout Switch: On-Off keyed lockout rated at 4 amps at 125 VAC restricts unauthorized access
• Open, Close, and Stop Buttons: Contacts rated at 12 amps at 600 VAC with both Normally Open and Normally Closed configurations
• Weatherproof Non-Metallic Enclosure: NEMA 3R, 4, and 12 rated for outdoor and industrial use
• Fully Guarded Design: Enhanced operator safety in industrial and outdoor settings
• Surface Mount Installation: Compact dimensions allow space-efficient mounting

Specifications

• Model: 3BXLT
• Enclosure: Non-metallic, NEMA 3R, 4, and 12 rated
• Button Electrical Rating: 12 amps at 600 VAC
• Keyswitch Electrical Rating: 4 amps at 125 VAC
• Contact Types: Normally Open and Normally Closed
• Mounting Type: Surface mount
• Dimensions: 7" H x 2-3/4" W x 2-1/2" D
• Certifications: UL Listed and CSA Approved

The MMTC 3BXLT delivers dependable, weatherproof control with built-in keyed lockout security for outdoor and industrial applications.
