EMX Industries 5250-K NIR-50 Retro-Reflective Photo Eye Kit
The EMX Industries 5250-K is a retro-reflective photo eye kit featuring a 50-foot sensing range, watertight IP66 enclosure, and flexible voltage support — kit includes photoeye with hood, reflector with hood, and mounting bracket.
Overview
The EMX Industries 5250-K NIR-50 is a retro-reflective photo eye kit designed to provide entrapment protection for gates and barriers. It offers an extended sensing range of up to 50 feet, a compact design, LED indicators, and flexible voltage compatibility, making it straightforward to install. The kit ships complete with a photoeye with hood, reflector with hood, and mounting bracket.
Key Features
- 50-foot sensing range for extended coverage
- Retro-reflective detection technology
- Sensitivity adjustment for fine-tuned performance
- Watertight IP66 enclosure (IEC) for environmental protection
- LED indicators for easy status monitoring
- Flexible voltage support: 12–240V DC, 24–240V AC
- 6-foot lead wire included
- Includes mounting brackets and hardware
- CE certified
- 2-Year Limited Manufacturer Warranty
Specifications
- Sensing Range: 50 feet
- Operating Voltage: 12–240 Volts DC, 24–240 Volts AC
- Operating Temperature: -20°C to +55°C (-4°F to +131°F)
- Response Time: 10 ms maximum
- Lead Wire: 6 feet
- Dimensions: H = 2.5", D = 1.5", W = 0.75"
- Fail Safe Relay Output: 125V AC 0.6A, 110V DC 0.6A, 30V DC 2A
- Environmental Protection: IP66 (IEC)
- Certifications: CE
Kit Contents
- Photoeye with hood
- Reflector with hood
- Mounting bracket
The EMX Industries 5250-K delivers reliable retro-reflective detection in a rugged, weather-resistant package — purpose-built for gate and barrier entrapment protection.
