FAAC 785105 Pair of XP 30 Photobeam Photocells

Overview

The FAAC 785105 delivers a pair of XP30 Wide-Range Photobeam Photocells engineered for gate opener safety in both wall-mounted and flush/column-mounted applications. The compact plastic body features a moulded seal on the front cover and a closed-cell seal in the cable routing area, providing maximum protection in extreme weather conditions while reducing the risk of damage from passing vehicles. These photocells are protected against interference from external light sources such as LED headlights, making them a reliable safety solution for demanding environments.

Key Features

• Maximum range: 100 ft. (30 m)
• 4-channel relay selection using coded signals — install up to 4 separate XP30 pairs close together with no minimum distance required and no need to reverse TX and RX positions
• Automatic alignment with an auto-alignment angle of 7 degrees to 13.5 degrees
• Plastic body with moulded front cover seal and closed-cell cable routing area seal
• Protected against interference from external light sources (including LED headlights)
• Suitable for wall-mounted or flush/column-mounted installation (adapter required for flush/column mount)
• UL 325 compliant when used with FAAC control boards
• Color: Black

Specifications

• Maximum Distance: 100 ft. (30 m)
• Power Supply Voltage: 24 AC or DC
• Absorbed Current: RX 30 mA, TX 20 mA
• Contact Ratings: 60 VA / 24 W
• Alignment: Automatic
• Auto-Alignment Angle: 7 Degrees – 13.5 Degrees
• Output Type: Relay – N.C./N.O.
• Protection Class: IP54
• Operating Temperatures: -4°F – 131°F
• Dimensions (L x H x D): 2.16" x 3" x 0.82"

Compatibility

• UL 325 compliant when used with FAAC control boards
• Compatible with wall-mount or flush/column-mount configurations — adapter brackets sold separately (FAAC 401065, FAAC 401064)

The FAAC 785105 XP30 photocells are the ideal replacement for both wall and flush mounted Fotoswitch and Photobeams.
