Transmitter Solutions PAL-SPIDER Wireless Wiegand 26 Control

Overview

The Transmitter Solutions PAL-SPIDER delivers a true plug-and-play access control solution combining virtual and physical credentials in a single wireless device. Operated through cloud-based software and a dedicated app, it requires no network connection and supports management of multiple access points from a single dashboard with unlimited event logs.

Key Features

• Virtual & Physical Credentials: Comes with 4 mobile credentials included; additional user licenses available per person (non-transferable, unique per person)
• App-Based Virtual Credentials: Open gates or doors via iOS or Android device
• Bluetooth Support: Use the PAL Gate App to open from anywhere or set a desired proximity for gate users
• Auto Open: Open by proximity using PAL Gate App, dialing, Siri, Google Assistant, or any external Wiegand 26 device
• Mechanical Relay: Enables use with MagLocks and Strikes without an additional external relay
• Works with ANY Wiegand Device: Compatible with transmitters, cards, fobs, RFID tags, and more
• Up to 60,000 Users
• 7-Day Automatic Unlock/Lock Schedule
• 1 Input Alert: Notifies an unlimited number of email addresses if gate or door is left open for a set amount of time
• Cloud-Based Software: Accessible via desktop web portal or dedicated PAL application; manage multiple access points from a single dashboard with unlimited event logs
• Cellular Connectivity: Supports 3G or 4G

Specifications

• Dimensions: 2" x 3" inches
• Input Voltage: 12–24VDC
• Power Consumption: 30mA
• Management Protocol Support: Web Portal and Application
• Connectivity: 3G or 4G
• Protocol: Wiegand 26

Mechanical Relay Specifications

• Maximum Switching Power: 30W, 62.5VA
• Maximum Switching Voltage: 220VDC, 250VAC
• Maximum Switching Current: 1A
• Maximum Carrying Current: 2A

Subscription & Licensing

• Includes 4 mobile credentials; additional user licenses are a one-time fee per user after the first 4
• Yearly subscription fee applies
• User licenses are non-transferable and unique per person

The Transmitter Solutions PAL-SPIDER is an advanced wireless access control solution built for flexible, scalable credential management.
