Transmitter Solutions PAL-VPS-B Video Panel System
The Transmitter Solutions PAL-VPS-B is a cloud-based video telephone entry system with a 7-inch touch screen, anti-vandal design, and support for up to 6,000 users.
Overview
The Transmitter Solutions PAL-VPS-B is a video telephone entry system that delivers a live video feed during calls. Operated through an intuitive cloud-based platform, it supports multiple access points from a single dashboard, unlimited event log viewing, and flexible user access management via desktop or the dedicated PAL application. The PAL-VPS-B features an anti-vandal design with anti-vandal glass and an ambient light sensor, making it a robust solution for demanding entry environments.
Key Features
- Supports up to 6,000 users
- 7-inch touch screen display interface
- Live video feed during calls
- Group Calling capability
- Cloud-based software — manage from desktop or PAL mobile app (Android / iOS)
- Manage multiple access points from a single dashboard with unlimited event logs
- Anti-vandal design with anti-vandal glass
- Ambient light sensor
- Built-in multi-protocol card reader
- Wiegand-26 output; available Wiegand input for auxiliary devices (cards, transmitters, UHF reader, etc.)
- Cellular connectivity: 4G / 3G / 2G
- Ethernet connectivity
- Bluetooth BT4.2 LE
- Fully-integrated IEEE 802.3-Compliant PoE+ PD
- Very low annual renewal cost regardless of number of users
- Custom powder-coated mounting options available: hood, post mount adapter, and cabinet pedestal
- Black case
Specifications
- Display Size: 7-inch
- Display Resolution: 720 x 1280
- Camera: 8M pixels, 120° view angle
- Cellular: 4G / 3G / 2G
- Bluetooth: BT4.2 LE
- NFC Frequency: 13.56 MHz
- Ethernet: RJ45, 10/100 Mbps
- Relay: 2 × Relays (N.O / N.C)
- Input: 2 × Input
- PoE: Fully-Integrated IEEE 802.3-Compliant PoE+ PD
- Card Reader Interface: NFCIP-1, NFCIP-2, ISO/IEC 14443, ISO/IEC 15693, MIFARE
- Speaker: Hidden powerful 15W / 4Ω
- Microphone: -42dB ±3dB @ 94dB SPL
- Power Supply: DC 48V and/or PoE+
- Power Output: DC 12V 2.5A
- Working Temperature: -20 to 65°C
- Size: 251.6 × 129.6 mm
- App Support: Android / iOS
- Mounting Options: Wall Mount, Post Mount
The Transmitter Solutions PAL-VPS-B combines cloud-based access management, multi-protocol credential reading, and video calling in a single anti-vandal panel built for professional installation.
