EMX Industries PATRIOT-E Long Range RFID Reader
The EMX Patriot-E is a long-range RFID reader that detects UHF EPC Gen2 tags from 18 to 25 feet, making it ideal for vehicle access control at gated communities, commercial sites, and industrial areas.
Long-Range RFID Reader for Vehicle Access Control
Meet the EMX Patriot-E, your go-to long-range RFID reader for secure vehicle access. Perfect for gated communities, commercial sites, and industrial areas, it offers reliable tag detection from 18 to 25 feet, even in tough conditions. With its circular polarized antenna and 7.5 dBi gain, you can trust it to perform.
This reader supports a variety of communication outputs like Wiegand, RS-232, RS-485, and OSDP, making it easy to integrate into your existing system. It reads UHF EPC Gen2 tags such as windshield and hang tags. Plus, you can customize settings for timing and tag filtering. The package includes a mounting bracket, power supply, and test tag, all housed in a durable IP65-rated enclosure for outdoor use.
Key Features
- Reliable tag detection from 18 to 25 feet
- Includes mounting bracket, power supply, and test tag
- Supports multiple communication outputs for easy integration
Programming & Configuration
- Easy configuration via PC software
- Adjust RF output, LED, and buzzer settings
- Manage up to 500 authorized tag numbers
Technical Specifications
- Frequency: 902–928 MHz
- Max RF Power: 30 dBm (1 Watt)
- Operating Temperature: -20°C to +70°C
Available Models
- Patriot-E: Circular polarized RFID reader with RS-232 programming
