DoorKing 1505-009 1520 Series Replacement Circuit Board
The DoorKing 1505-009 is a replacement circuit board for 1520 Series access controllers, supporting up to 1,000 user codes and 3,656 transaction events with 26-bit Wiegand compatibility (memory chip sold separately).
Replacement Board for Doorking 1520 Series Access Controllers
The Doorking 1505-009 is your go-to replacement circuit board for the 1520 Series access control systems, including the 1520-081 controller. It works seamlessly with 26-bit Wiegand-compatible devices. This board features time zone programming, anti-pass back, and transaction logging for enhanced security.
Important: The memory chip is not included. You will need to transfer it from your original board or purchase it separately.
Key Features
- Compatible with Doorking 1520 Series controllers
- Supports 1,000 user codes and programmable time zones
- Stores up to 3,656 transaction events
Technical Specifications
- Model: 1505-009 (Rev E or higher)
- Power Requirements: 16 VAC or 12–24 VDC
- Relay Output: Form C, 30V, 1A max
Conclusion
The Doorking 1505-009 circuit board helps you restore access control to your 1520 Series controllers. Don’t forget to install a compatible memory chip for full functionality, as it is not included with this board.
