EMX Industries 1500-2 Thru-Beam Photo Eye BPE-50
The EMX Industries 1500-2 is a thru-beam photo eye with a battery-powered transmitter, offering up to 50 feet of range and a 2-year expected battery life. Made in the USA and backed by a 2-Year Limited Manufacturer Warranty.
Overview
The EMX Industries 1500-2 (formerly BPE-50) is a thru-beam photo eye designed for gate applications. The transmitter can be powered by two included 3.6-volt lithium batteries with an expected life of up to approximately 2 years, while the transmitter and receiver also support 12–24 VDC/AC power. A built-in energy efficient power save option and 90° left or right adjustment capability make this a flexible, field-ready safety device. Replaces part number BPE-50.
Key Features
- 50-foot range thru-beam configuration
- 90° adjustment left or right
- Energy efficient power save option
- Transmitter operable on two 3.6-volt lithium batteries (included)
- Expected battery life: up to 2 years (approx.)
- Red LED detection indicator
- Sensitivity adjustable via Jumper J1 on receiver
- IP 65 environmental rating
- 2-Year Limited Manufacturer Warranty
- Made in the USA
Specifications
- Power Supply: 12–24 VDC / 24 VAC (or two 3.6-Volt Lithium Batteries for transmitter)
- Relay Type: 2 Form C DPST — contact rating 0.5A @ 24VDC / 120VAC
- Relay Contact: 0.5A
- Temperature Range: -20°C – 55°C
- Wavelength: 880 nm
- Frequency: 787 Hz
- Environmental Rating: IP 65
- Detection Angle: ±5°
- Housing Material: PA6 30% FG
- Size: H 4.4 in (112 mm) × W 2.05 in (52 mm) × D 1.3 in (33 mm)
- Range: Up to 50 feet
- Connector: Terminal block
- Detect Indicator: Red LED
- Sensitivity: Jumper J1 on receiver
- Manufacturer Part Number: EMX-1500-2
The EMX Industries 1500-2 delivers reliable thru-beam detection with the flexibility of battery-powered operation — a dependable solution for gate safety applications.
