Linear 0-291312RU Plug-In 12 VDC Power Supply

Overview

The Linear 0-291312RU is a plug-in, EISA compliant power supply that delivers 12 VDC output at 2000 mA (2 amps) maximum from a 120 VAC input. It functions as a transformer and power supply in one, plugging directly into an AC outlet with no separate cabinet required.

Key Features

• Regulated output voltage at ±1% from 0% to 100% load, expanding options for low-load and high-load applications
• Auto-resetting poly fuse automatically resets after a short circuit, reducing unnecessary service calls
• Robust surge protection guards against AC line spikes and transients to protect the power supply and connected equipment
• Ground prong on AC power input and ground output terminal for input protection and easy panel ground connection
• Red LED power indicator provides at-a-glance confirmation that the supply is operating
• Knockout for wall outlet retaining screw for quick, secure installation
• Plugs directly into AC outlet — no cabinet to mount

Specifications

• Input Voltage: 120 VAC
• Output Voltage: 12 VDC
• Output Current: 2000 mA (2 amps) maximum
• Compliance: EISA compliant
• Dimensions: 2.5" W x 3.5" H x 2.25" D
• UPC: 783950913124

The Linear 0-291312RU is a reliable, installation-ready power supply built to perform consistently across a wide range of load conditions.
