Altronix SMP3 Power Supply Charger

Altronix SMP3 Power Supply Charger

The Altronix SMP3 power supply/charger converts a low voltage AC input into a 6VDC, 12VDC, or 24VDC output. This unit has a wide range of applications for access control, security, and CCTV system accessories that require additional power. Its extremely compact board design makes it ideal for installations where space is limited.

Key Features

• Selectable Output: 6VDC, 12VDC, or 24VDC selectable output
• 2.5A continuous supply current
• Filtered and electronically regulated output
• Short circuit and thermal overload protection
• Built-in charger for sealed lead acid or gel type batteries
• Automatic switchover to stand-by battery when AC fails
• Battery short circuit protection (circuit breaker)
• AC input and DC output LED indicators
• Extremely compact design
• Includes battery leads
• Snap Track compatible

Specifications

• Input: 16VAC to 28VAC
• Output: 6VDC, 12VDC, or 24VDC selectable @ 2.5A continuous
• Operating Temperature: 0°C to 49°C (32°F to 120°F)
• Storage Temperature: -20°C to 70°C (-4°F to 158°F)
• Relative Humidity: 85% ±5%
• BTU/Hr (approx.): 6VDC: 8 BTU/Hr | 12VDC: 15 BTU/Hr | 24VDC: 31 BTU/Hr

Applications

• Access control systems
• Security systems
• CCTV system accessories

Note: Batteries are sold separately.

The Altronix SMP3 delivers reliable, regulated power with built-in charging and protection features trusted in professional security and access control installations.
