EMX Industries 1805-1 Free Exit Vehicle Detection Probe (PROBE-50) CS-101
The EMX Industries 1805-1 is the (PROBE-50) CS-101 free exit sensing probe featuring a 50-foot shielded direct burial lead-in cable and a control module with an 11-pin connector — built for vehicle detection in access control, safety, and security applications.
Overview
The EMX Industries 1805-1, also known as the (PROBE-50) CS-101, is a CarSense 101 vehicle motion detector consisting of a control module with a standard 11-pin connector and a sensing probe designed for easy installation along a roadway. The system can be seamlessly integrated with security control boards, gate operators, and parking barriers. The control unit is housed in a break-resistant Polycarbonate enclosure, and the probe features a PVC watertight housing with a shielded direct burial lead-in cable. Made in USA.
Key Features
- Controls and indicators mounted on front panel
- Available in 9–41 VDC / 6–29 VAC power supply options
- Low 2.5 mA standby current consumption — well suited for solar power applications
- Housed in a small, relay-type housing
- Surge protection via MOV, neon, and silicon protection devices
- High intensity Green LED Power On indicator
- High intensity Red LED Detect indicator
- Continuous adjustment Sensitivity Control
- Continuous adjustment Off Delay Control
- Buried sensing probe protects against potential intruders
- Easy upgrade or switch out to new devices
Specifications
- Power Supply: 9–41 VDC / 6–29 VAC or 110VAC
- Power Supply Tolerance: +/-20% from the power rating
- Stand-by Current: 2.5 mA maximum
- Detect Current: 50 mA maximum
- Relay Type: DPDT
- Relay Rating: 1A 24V DC / 120V AC
- Sensitivity: High, Low adjustment
- Off Delay: 1 to 5 seconds adjustment
- Control Unit Temperature Range: -40°F to 170°F
- Probe Temperature Range: -40°F to 170°F
- Control Unit Housing: Break-resistant Polycarbonate — H: 2.2" (55mm), W: 1.6" (41mm), D: 3.25" (84mm)
- Connector: 86CP11 11-pin connector
- Probe Housing: PVC watertight — Length 17", Diameter 1"
- Lead-in Cable: 50-foot shielded direct burial cable
Compatibility
The CS-101 is designed to integrate with security control boards, gate operators, and parking barriers for access control and safety applications.
Replaces part number PROBE-50. The EMX Industries 1805-1 delivers reliable vehicle detection in a compact, field-ready package built for demanding installation environments.
