EMX Industries 100-P-300-HA Proximity Reader Mini-Mullion

Overview

The EMX Industries 100-P-300-HA is a mini-mullion proximity reader built on 125-kHz Proximity RFID technology. Designed for electronic access control systems, it delivers a reliable read range of up to 5 inches (126 mm) and requires no battery, operating as a fully passive device. Value-add features include MAXSecure™ and fleaPower™ to meet specific installation needs.

Key Features

• Proven 125-kHz Proximity RFID technology
• Compact form factor: 1.7"W x 3.2"H x 0.7"D (43 mm x 81 mm x 18 mm)
• Read range up to 5 inches (126 mm)
• Passive device — no battery required
• MAXSecure™ and fleaPower™ features included
• Versatile mounting: mullions, metal door and window frames, and other surfaces
• Certifications: FCC, ICC, CE, C-Tick, UL Standard 294, IP67

Specifications

• Operating Frequency: 125 kHz
• Dimensions: 1.7"W x 3.2"H x 0.7"D (43 mm x 81 mm x 18 mm)
• Read Range: Up to 5 inches (126 mm)
• Weight: 3 oz (85 g)
• Power Supply: +5–16 VDC, 30 mA typical, 75 mA peak @ 12 VDC
• Operating Temperature: -40°F to 149°F (-40°C to +65°C)
• Certifications: FCC, ICC, CE, C-Tick, UL Standard 294, IP67

Compatibility

• Pyramid Series Proximity Cards and Tags
• Certain HID 125-kHz Proximity protocols
• Certain AWID 125-kHz Proximity protocols
• Compatible with a wide range of electronic access control systems

The EMX Industries 100-P-300-HA delivers dependable, passive proximity reading in a compact mullion-mount form factor suited for demanding access control environments.
