Viking Access Systems R6NX Swing Gate Operator Residential - Operator Only
The Viking Access Systems R6NX is a residential single swing gate operator handling gates up to 700 lbs. and 14 ft., featuring a V-Flex control board with on-board diagnostics LCD display and integrated true battery backup. Operator only; accessories sold separately.
Overview
The Viking Access Systems R6NX Residential Swing Gate Operator is built for heavy residential swing gate applications, handling gates up to 700 lbs. and 14 ft. in length. It features the V-Flex control board with an on-board diagnostics LCD display and a new chassis design for easy viewing of controls. A built-in thermostat controlled heater, on-board temperature management system, integrated true battery backup, and LED status indicators for incoming high voltage make the R6NX a capable choice for residential swing gate installations. Compatible gate materials include wood, steel, aluminum, vinyl, and others.
Key Features
- V-Flex control board with on-board diagnostics LCD display
- Adaptive motor control
- Adjustable speed control
- Soft start / soft stop
- Built-in thermostat controlled heater
- Built-in voltmeter
- True battery backup — two 4Ah batteries included
- Battery backup: 400 continuous cycles
- Lightning strike protection
- UL325 compliant — Class I
- 100% duty cycle
- On-board display
- LED status indicators for incoming high voltage
- Convenient fuse access
- Two monitoring inputs with up to 4 devices per input
- 120V AC outlet provided
- Anti-tailgating feature
- Fail secure mode
- Fail safe mode
- Manual release — mechanical
- Multiple power outage options
- Multiple power options
Specifications
- Maximum Gate Capacity: 14 ft. at 700 lbs.
- Opening Angle: 120°
- Gate Speed: 13–16 sec./90°
- UL 325 Classification: Class I
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Main Power: 120/240 VAC Single Phase
- Voltage Current Specs: 120V AC – 2.5A or 240VAC – 1.5A
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Alternative Power Source: 24VAC / VDC (60VA) or Solar
- Accessory Power: 24VDC – 750mA
- Power Consumption – Idle: 70mA
- Motor Current (Typical): 4.0A
- Power Wire Specification: 10 gauge wire (purchased separately), maximum distance of 500 ft.
- Operating Temperature: -20°F (-28°C) to 160°F (71°C)
- Battery Backup: 400 continuous cycles
- Gate Post Requirement (pull to open): Maximum 3.00" OD pipe
- Warranty: 5-year manufacturer warranty
- Included Control Board: VFLEXPCBU18
The Viking Access Systems R6NX delivers reliable performance for residential swing gate installations where gate capacity, integrated backup power, and on-board diagnostics are essential.
What's Included
- (1) R6 Swing Gate Operator
This listing is for the gate operator only. Remotes, receivers, photocells, and other accessories are sold separately.
