Remote Control Solutions UR Universal Programmable Receiver
The Remote Control Solutions UR is a universal, configurable receiver for garage doors, gates, and entry systems, supporting six plug-in frequency cards (295, 300, 310, 318, 418, and 433 MHz) and multiple output options for flexible installation.
Overview
The Remote Control Solutions UR Universal Configurable Receiver is built for maximum compatibility across garage door, gate, and entry access control applications. It accepts six interchangeable plug-in frequency cards — 295, 300, 310, 318, 418, and 433 MHz — enabling seamless integration with nearly any transmitter system. The UR supports one or two receiver cards, and frequency cards are sold separately.
Key Features
- Accepts six plug-in frequency cards: 295, 300, 310, 318, 418, and 433 MHz
- Supports 26-bit and 30-bit Wiegand access control systems
- Compatible with both Wiegand-programmable and dip-switch transmitters
- Multiple output options: 3-wire 485 BUS RF output, NO/NC relay, and 4-wire Wiegand terminal
- DIP-switch configurable bit format for straightforward setup
- Accepts one or two RCS receiver cards
- Frequency cards sold separately for easy customization
Specifications
- Supported Frequencies: 295, 300, 310, 318, 418, 433 MHz (via plug-in cards)
- Wiegand Formats: 26-bit and 30-bit
- Outputs: 3-wire 485 BUS RF, NO/NC relay, 4-wire Wiegand terminal
- Configuration: DIP-switch configurable bit output
- Receiver Card Capacity: One or two cards
Compatible Frequency Cards
- RCS-433RC (433 MHz)
- RCS-418RC (418 MHz)
- RCS-318RC (318 MHz)
- RCS-310RC (310 MHz)
- RCS-300RC (300 MHz)
- RCS-295RC (295 MHz)
The Remote Control Solutions UR delivers versatile, configurable performance for residential, commercial, and industrial access control installations.
