Transmitter Solutions RECTSMULFRE4 Multi-Frequency Wiegand R
SKU
ts-rectsmulfre4
The Transmitter Solutions RECTSMULFRE4 is a HIVE Wiegand Output Receiver supporting 295 MHz, 318 MHz, 418 MHz, and 433 MHz frequencies, with 26-bit or 30-bit Wiegand output and a 5-year warranty.
Overview
The Transmitter Solutions RECTSMULFRE4 is a multi-frequency Wiegand output receiver designed for outdoor use. It reads two frequencies simultaneously across four supported bands — 295 MHz, 318 MHz, 418 MHz, and 433 MHz — allowing existing remotes to remain in service while new ones are introduced. Plug-in slots and receiver modules provide flexibility for various frequency configurations.
Key Features
- Dual-band operation: Reads two frequencies simultaneously
- Supported frequencies: 295 MHz, 318 MHz, 418 MHz, and 433 MHz
- Wiegand output: 26-bit or 30-bit selectable
- Plug-in slots and receiver modules for various frequency options
- Keep existing remotes while introducing new ones
- Outdoor rated with IP protection
- 5-year warranty
Specifications
- Input Power: 12–24V AC/DC
- Power Consumption: 24mA Max
- Output Current: 250mA Max
- Output Type: Wiegand
- Operating Temperature: -40°F to 158°F
- Dimensions: 4 x 4 x 2 in
- Weight: 2.3 oz
- Warranty: 5 Years
The Transmitter Solutions RECTSMULFRE4 delivers versatile multi-frequency reception with Wiegand output in a durable, outdoor-rated enclosure.
