ProDataKey RGPB Single-Gang High-Security Proximity Reader

ProDataKey RGPB Single-Gang High-Security & Mobile-Ready Red™ Proximity Reader

The ProDataKey RGPB is part of the Red™ Reader line — one of the most secure and versatile reader platforms available today. Designed for applications ranging from everyday access control installations to the most demanding high-security environments, the RGPB combines OSDP secure connectivity, dual-frequency communication, and mobile-ready functionality in a compact single-gang form factor.

Red™ Readers are in a class of their own, offering cutting-edge encryption and broad credential compatibility. Whether you are upgrading an existing system or deploying a new high-security access control solution, the RGPB delivers the flexibility and protection your project demands.

Key Features

• OSDP Secure Connectivity: Supports OSDP protocol for encrypted, bidirectional communication between the reader and controller, significantly enhancing system security over traditional Wiegand.
• Wiegand Output: Also supports standard Wiegand protocol for backward compatibility with existing access control systems.
• Dual-Frequency Communication: Reads both high-frequency (13.56 MHz) and low-frequency (125 kHz) credentials, providing broad compatibility with a wide range of proximity cards and fobs.
• Mobile-Ready: Equipped with mobile credential support, allowing users to utilize smartphones as access credentials for a seamless, modern entry experience.
• MIFARE® DESFire® EV2 Encryption: Supports advanced DESFire EV2 encryption for the highest level of credential security, protecting against cloning and unauthorized duplication.
• Single-Gang Form Factor: Fits standard single-gang electrical boxes for clean, professional installations on virtually any door frame or wall surface.
• Read Range: Up to 4 inches at 125 kHz for reliable credential detection without requiring users to make direct contact with the reader.

Specifications

• Model: RGPB
• Manufacturer: ProDataKey (PDK)
• Reader Type: Proximity + Mobile
• Form Factor: Single-Gang
• Frequency: Dual — 125 kHz (low) and 13.56 MHz (high)
• Read Range (125 kHz): Up to 4"
• Output Protocols: OSDP and Wiegand
• Encryption: MIFARE® DESFire® EV2
• Mobile Credentials: Supported

Applications & Compatibility

The ProDataKey RGPB is ideal for a wide range of access control applications, including commercial offices, multi-tenant buildings, government facilities, healthcare campuses, and any environment where high-security credential authentication is required. Its dual-frequency capability ensures compatibility with legacy 125 kHz proximity cards while supporting the latest 13.56 MHz smart card technology and mobile credentials.

The RGPB integrates seamlessly with ProDataKey cloud-based access control systems and is also compatible with third-party controllers that support OSDP or Wiegand communication protocols.

Quality & Reliability

As part of the ProDataKey Red™ Reader family, the RGPB is engineered to deliver exceptional reliability and long-term performance. With its combination of advanced encryption, versatile credential support, and secure communication protocols, this reader provides a future-proof solution that meets the evolving security needs of modern facilities. Trust ProDataKey for access control technology that sets the standard in security and convenience.
