DoorKing 8080-406 6ft LED Reverse Edge Safety Device

DoorKing 8080-406 Reverse Edge with LED Indicators — 6 ft

The DoorKing 8080-406 is a 6 ft reverse edge safety device equipped with integrated red and green LED indicators, designed specifically for use with DoorKing 1601 barrier gate operators. This essential safety accessory enhances both visibility and protection in high-traffic areas by providing clear visual signaling and reliable obstruction detection. It replaces previous models including the 8080-306 and 8080-305.

When the barrier arm is raised, the integrated LEDs illuminate green, signaling that vehicles and pedestrians may proceed. When the arm is lowered, the LEDs display red, providing a clear warning to stop. This dual-color LED system significantly improves safety, especially in low-light conditions and busy commercial or residential access points.

In addition to its visual signaling capability, the 8080-406 reverse edge features obstruction detection. When the barrier arm encounters an obstacle during operation, the reverse edge triggers an automatic reversal of the arm, helping to prevent damage to vehicles and reducing the risk of injury to pedestrians.

Key Features

• LED Indicators — Integrated red and green LEDs provide clear signaling: green when the arm is raised and red when lowered, enhancing visibility for drivers and pedestrians.
• Obstacle Detection — Automatically triggers arm reversal upon contact with an obstruction, preventing damage and improving safety.
• Seamless Integration — Designed to work exclusively with DoorKing 1601 barrier gate operators for reliable, purpose-built performance.
• Wiring Harness Required — Must be paired with the DoorKing 1601-356 Wiring Harness (sold separately) for full LED and reverse edge functionality.
• Direct Replacement — Replaces previous DoorKing models 8080-305 and 8080-306, making upgrades and replacements straightforward.

Specifications

• Manufacturer SKU: 8080-406
• Length: 6 ft
• LED Colors: Red (arm lowered), Green (arm raised)
• Replaces: 8080-305, 8080-306
• Required Accessory: DoorKing 1601-356 Wiring Harness
• Condition: New

Compatibility & Application Notes

The DoorKing 8080-406 reverse edge is engineered exclusively for use with DoorKing 1601 barrier gate operators. It is not intended for use with other gate operator models. For full functionality — including both the LED signaling and the reverse edge safety features — the 1601-356 Wiring Harness is required and must be purchased separately. This reverse edge is an ideal upgrade for facilities currently using older models such as the 8080-305 or 8080-306.

Whether you are managing a parking facility, gated community, commercial property, or any controlled-access point, the DoorKing 8080-406 delivers the combination of enhanced visibility and reliable obstruction protection needed to maintain a safe environment. Built to DoorKing's exacting standards, this reverse edge provides dependable, long-lasting performance you can count on.
