Security Brands Ridge 14-HD500 Wireless Keypad HD & Transcei
Security Brands Ridge Keypad HD (14-HD500) — 433-MHz wireless post-mount keypad with heavy-duty steel enclosure and transceiver, 500-code capacity.
Security Brands Ridge Keypad HD and Transceiver — 433 MHz — Post Mount
The Security Brands Ridge Keypad HD (Model 14-HD500) is a professional-grade wireless access-control solution designed for gates and doors. Featuring a heavy-duty powder-coated steel enclosure with a stainless-steel faceplate and a backlit metal keypad, this unit delivers durability and visibility in any environment. The included 433-MHz Ridge Transceiver completes the system, providing reliable wireless communication at a range of up to 500 feet.
Because the keypad is powered by a single 9-volt battery and communicates wirelessly, it can be post-mounted virtually anywhere — no trenching or conduit required. Security Brands' innovative Ridge Wireless™ technology offers one of the most versatile and responsive wireless access-control platforms available.
Key Features
- LED-Backlit Keypad: Metal keypad with LED backlighting for easy use in low-light conditions.
- 500 Four-Digit Access-Code Capacity: Store up to 500 unique four-digit codes for large user bases.
- Wireless Range Up to 500 Feet: Reliable 433-MHz communication between keypad and transceiver.
- Control Up to 2 Gates or Doors: Operate two separate access points from a single keypad (requires two Ridge Transceivers).
- Connect Up to 40 Devices: Link up to 40 keypads and/or remotes to a single transceiver.
- Latch Mode: Built-in wireless latch mode for sustained gate or door activation.
- Personal Master Code: Assign a secure personal master code for system administration.
- Limited-Use Code: Program temporary codes with 1 to 9 uses for visitors or contractors.
- "3 Strikes, You're Out" Security: Lockout feature after three incorrect code attempts to deter unauthorized access.
- Variable Relay Time: Adjust the transceiver relay duration to match your gate operator or door strike requirements.
- Audible-Tone Feedback: Audio confirmation of key presses and valid/invalid code entries.
- 9-Volt Battery Powered: Single 9-volt battery powers the keypad — no hardwiring needed at the keypad location.
- Non-Volatile Memory: All programmed codes and settings are retained even during battery replacement.
Specifications
- Model: 14-HD500
- Frequency: 433 MHz
- Power (Keypad): 9 VDC (single 9-volt battery)
- Code Capacity: 500 four-digit codes
- Wireless Range: Up to 500 feet
- Keypad/Remote Capacity per Transceiver: Up to 40
- Gate/Door Control per Keypad: Up to 2 (with two transceivers)
- Mounting: Post mount (keypad); transceiver mounts in any protective enclosure
- Construction: Powder-coated steel enclosure with stainless-steel faceplate
- Memory: Non-volatile
Applications & Compatibility
The Ridge Keypad HD is ideal for gated communities, commercial facilities, parking areas, and any location requiring wireless access control. The post-mount keypad installs quickly at the entry point, while the transceiver can be placed near the gate operator or electric strike in any protective enclosure. For dual-gate control from a single keypad, two Ridge Transceivers are required.
Built with a rugged powder-coated steel body and stainless-steel faceplate, the Ridge Keypad HD is engineered to withstand demanding outdoor environments while delivering dependable, long-term wireless access control from Security Brands.
