FAAC 10430115_5 S418 Swing Gate Operator Secondary Kit

Overview

The FAAC 10430115_5 S418 Secondary Kit is a low voltage secondary swing gate arm designed to convert your existing S418 single kit into a full dual swing gate opener. Supporting gates up to 12 feet long and 500 pounds, this kit provides everything needed to create a bi-parting gate setup for residential driveway applications. Replaces part number 10430115.5.

Kit Includes

• 1 x S418 Swing Gate Operator
• 1 x Junction Box for electrical connections
• 1 x 40 ft cable, AWG 12, 2 conductors

Key Features

• Sleek, streamlined design with built-in mechanical stops
• Simple installation with multi-position, non-welded mounting bracket
• Battery backup support through primary control board
• Complies with UL325 Safety Standards — Class I, Class II, Class III, Class IV
• Pairs with S418 primary system for complete dual gate functionality
• Maximum opening angle: 90 degrees

Specifications

• Actuator Voltage: 24V DC
• Controller Input Voltage: 110/115/120V AC (60 Hz, 1 Phase)
• Power: 35 W
• Current: 1.5 A
• Max Thrust: 404 lbf (180 daN)
• Rod Stroke: 13.8 in (15.3 in without stops)
• Rod Speed: 0.7 in/sec
• Max Gate Weight: 500 lb
• Max Gate Length: 12 ft
• Operating Temperature: -4°F to 131°F
• Use Frequency: Continuous
• Protection Class: IP 54
• Color: Painted Steel

Compatibility

• Designed to pair exclusively with the FAAC S418 primary single swing gate opener kit

Complete your dual swing gate system with the FAAC 10430115_5 S418 Secondary Kit — a reliable, UL325-compliant secondary operator built for residential driveways.
