BD Loops SC 24-50 4x8 or 6x6 Preformed Saw-Cut Inductance Loop, 50' Lead-In
BD Loops SC 24-50 is a complete preformed saw-cut vehicle detection loop designed for concrete or asphalt. It offers a 24’ perimeter for 4x8 or 6x6 loop patterns and includes a 50 ft lead-in. Built with 16 AWG copper wire, a protective outer jacket, and a built-in backer rod, it installs cleanly in a 3/16” saw-cut groove.
BD Loops SC 24-50 is a complete preformed saw-cut vehicle detection loop designed for installation in a 3/16” saw-cut groove in concrete or asphalt. The loop perimeter is 24’ and fits a 4x8 or 6x6 loop pattern, with a 50 ft lead-in to route back to the loop detector. A thick, durable outer jacket protects and tightly binds the conductors on both the loop and lead-in for long-term reliability. This loop is made with 16 AWG copper wire. The built-in backer rod helps the loop sit properly in a 3/16” groove and eliminates the need for additional backer rod. Each loop is tested multiple ways before leaving the factory to support dependable vehicle detection.
Gate Design Tools
Use these BD Loops calculators to size your saw cut loop and estimate sealant for your gate setup:
