Select Engineered Systems CAT10HF-2700 Access Control System
The Select Engineered Systems CAT10HF-2700 is an all-in-one automatic call, entry, and card reader access control system featuring a 10-line display, 2,700 phone capacity, and 16,200 card capacity.
Overview
The Select Engineered Systems CAT10HF-2700 is an automatic call, entry, and card reader access control system in a single device. Its 10-line LCD Transflective display helps visitors navigate the unit, and the first two lines can be programmed by users. The system can be expanded to 16 doors and 255 relay points to control elevators, HVAC, lights, or other facility applications. Programming is supported via SELCOM software over the internet, or through the built-in model, IP (NIC), RS232, or wireless interfaces. Includes an NIC3 Network Interface Card and board-level surge suppression.
Key Features
- Phone Capacity: 2,700
- Card Capacity: 16,200
- 10-line LCD Transflective Display
- CAT 10 character size: 1/2"
- First two lines programmable by users
- 2 Wiegand Card Reader Inputs
- RS485 Expansion Port
- Expandable to 16 doors and 255 relay points
- 2 relays included with board-level surge suppression
- Includes NIC3 Network Interface Card
- Non-volatile memory
- Standard voice grade RJ11C telephone line jack
Specifications
- Model: CAT10HF-2700
- Housing Material: 12 Gauge Aluminum
- Door Material: 16 Gauge Stainless Steel
- Finish: Weather-Resistant Aluminum Back Box
- Mounting: Surface, Flush, or Pedestal
- Dimensions: 9 1/2" W x 13 1/2" H x 3 1/8" D
- Power Input: 16.5 VAC, 20 VA UL Listed Transformer
- Memory Type: Non-Volatile
- Telephone Line: Standard Voice Grade RJ11C Jack
The Select Engineered Systems CAT10HF-2700 delivers flexible, scalable access control for demanding professional installations.
