Select Engineered Systems RPNIC3 Network Interface Card

Overview

The Select Engineered Systems RPNIC3 is an optional, field-installable Network Interface Card that provides a plug-in TCP/IP interface for all CAT and most TEC series products. The RPNIC3 is powered directly from the connected CAT or TEC unit and ships pre-assigned with a MAC address and a default TCP/IP address. Lantronix Com Port Redirector configuring software and the product manual are included on CD. A serial port remains active on the RPNIC3 whenever an Ethernet session is not in progress; at the end of any Ethernet session, the card automatically reverts to serial communications.

Key Features

• TCP/IP network compatible
• Communicates with all CAT, TEC, and TEC1 series telephone access systems, including CAT Card
• Serial communications active at all times except during an active Ethernet session
• Automatically reverts to serial communications when an Ethernet session ends
• Supports both network access and local serial port control of Select Engineered Systems products
• Compatible with products running Selcom Secured or TEC Basic software
• Capable of up to 99 RPNIC3 units on a single network when running Selcom Premium
• Configurable through DHCP or individual IP address assignment
• Requires a qualified network manager for setup

Specifications

• Ethernet: 10/100 Mbps, RJ-45 connector
• RS-232: DB-9 or wiring terminal connector
• Signals Required: Transmit, Receive, Busy, Common
• Cabling Length: 100M for CAT5 UTP
• Interface: Web-based LAN session through RJ-45; Telnet session through DB-9 serial port or terminal connections; serial communications through DB-9 or terminal connections

Compatibility

• Compatible with all CAT and TEC series products
• Compatible with TEC1 series
• Not compatible with TECVision

The Select Engineered Systems RPNIC3 delivers reliable network integration for CAT and TEC access control installations.
