Select Engineered Systems SG2C Select Gate II Com
The Select Engineered Systems SG2C (SELECT GATE II COM) delivers flexible access control for residential and commercial applications, supporting PIN access, optional Card or Select Pass transmitter capability, and 9 programmable time zones.
Overview
The Select Engineered Systems SG2C SELECT GATE II COM is engineered for access control in residential and commercial settings, including hospitals, gated communities, retirement homes, and residential properties. It supports PIN access and optional Card or Select Pass transmitter capabilities, and offers "dated and timed" cards and PINs for visitors, deliveries, and contractors. A "Do Not Disturb" mode provides additional owner control.
Key Features
- DSL Filtering
- 100 pin codes programmable by time zone
- 26-Bit Wiegand Input
- 9 programmable time zones for access control
- Calls 10 additional numbers
- LED lighting
- Local call waiting and transferring
- Program by keypad or touch tone phone
- Latch gate open from keypad or touch tone phone
- Weather-resistant housing
- "Do Not Disturb" mode
- "Dated and timed" cards and PINs for visitors, deliveries, and contractors
Specifications
- Dimensions: 7" H x 9 7/16" W x 4 9/16" D
- Material: .090 Aluminum, primed and painted black texture for external use
- Front Door: Brushed stainless steel
- Operating Temperature: -20 degrees F to 140 degrees F
- Tone Detection: Crystal controlled, capable of detecting short burst 50ms and DTMF tone (detects touch-tones only)
- Relay Output (2): Form C dry contact 24V @ 3 amps
- Telephone Interconnect: RJ31X jack supplied
- Power Input: 16.5 VAC 20 VA plug-in transformer
- Part Number: SG2C
The Select Engineered Systems SG2C is a versatile, weather-resistant access control solution built to perform across a wide range of residential and commercial environments.
