AWID MM-6800-GR-MP 125kHz Mullion Proximity Reader

AWID-MM-6800-GR-MP Sentinel-Prox™ Mullion Proximity Reader

The AWID-MM-6800-GR-MP Sentinel-Prox™ Mullion Reader delivers reliable, high-performance proximity card reading for access control systems. Designed in a slim, weather-resistant housing, this reader is ideal for installation on door frames, mullions, or tight spaces where a compact footprint is essential.

Offering consistent read ranges and quick response times, the Sentinel-Prox™ series ensures dependable access verification for indoor and outdoor applications. It’s fully compatible with standard Wiegand output systems, making integration seamless across most access control panels and controllers.

Key Features

• Compact mullion design for easy mounting on narrow door frames
• Read range up to 6 inches with AWID proximity cards and tags
• Weather-resistant housing suitable for indoor or outdoor environments
• Standard Wiegand output for universal access control compatibility
• LED and beeper indicators for visual and audible feedback
• Low power consumption for energy-efficient operation

Applications

The AWID-MM-6800-GR-MP is ideal for door entry, gate access, or perimeter control points where a narrow-profile reader is required. Commonly used in offices, gated communities, and secured facilities.

Technical Specifications

• Technology: 125 kHz proximity
• Read Range: Up to 6 inches (varies by card/tag)
• Output Format: Wiegand (26–50 bits typical)
• Operating Voltage: 5 – 12 VDC
• Current Draw: 60 mA typical
• Indicators: Red/Green LED and internal beeper
• Dimensions: 1.7" W × 6.1" H × 1.0" D
• Mounting: Mullion / narrow door frame / wall mount
• Environment: Indoor or outdoor rated (sealed housing)

Conclusion

Compact, durable, and compatible with most access control systems, the AWID-MM-6800-GR-MP Sentinel-Prox™ Mullion Reader provides secure and efficient access identification wherever space or aesthetics demand a slim, modern reader.
