LiftMaster 811LMX Programmable DIP Remote Control

Overview

The LiftMaster 811LMX is a single-button programmable DIP switch remote control designed to replace multiple LiftMaster transmitters with one convenient unit. It is ideal for gated communities and commercial applications requiring a large number of remote controls for a common entrance. The 811LMX defaults to Security+ 2.0 Encrypted DIP (811LM) mode and can be reprogrammed to operate on 315 MHz DIP (361LM) or 390 MHz DIP (61LM / 61LMC) frequencies, simplifying inventory management and service calls.

Key Features

• Single-button programmable DIP switch transmitter
• Defaults to Security+ 2.0 Encrypted DIP mode
• Programmable to three frequency modes: Security+ 2.0 Encrypted DIP (811LM), 315 MHz DIP (361LM), and 390 MHz DIP (61LM / 61LMC)
• Able to clone to the 892LT and 894LT Learning Remote Controls as any of the DIP programming options
• Integrated LED indicator displays battery strength and transmission status
• Compact, durable housing
• Straightforward programming via DIP switch panel and Program button

Programming Instructions

• Open the top cover to access the DIP switch panel
• Locate the Program button to the right of the DIP switches
• Press the Program button once to enter program mode
• Press the transmitter button: once = 811LM Mode | twice = 361LM Mode | three times = 61LM Mode
• Press the Program button again to exit programming mode

Compatibility

• Replaces part number 811LM
• Replaces part number 361LM
• Replaces part number 61LM
• Replaces part number 61LMC
• Compatible with LiftMaster commercial operators and radio receivers
• Clonable to 892LT and 894LT Learning Remote Controls

The LiftMaster 811LMX is the single programmable remote that covers multiple legacy DIP systems, making it the smart choice for commercial and multi-unit residential access control applications.
