Transmitter Solutions DOLMGK-H Single Gang Wiegand Keypad Re

Overview

The Transmitter Solutions DOLMGK-H is a single gang Wiegand card reader and keypad designed for access control installations. It supports HID® 26-Bit Wiegand and mounts in a standard single gang configuration. The unit features tamper protection and a metal back plate for added security.

Key Features

• Non-scratch surface
• HID® 26-Bit Wiegand compatibility
• Touch sensor keypad
• Metal back plate
• Non-drop bottom screw
• Intended for indoor use
• Tamper protection
• Single gang mount

Specifications

• Protocol: 26-Bit Wiegand
• Proximity Card Reader: HID®
• Read Range: 2–5 cm
• Operating Voltage: 10V–15VDC
• Operating Current: 160mA (max)
• Temperature Rating: -22°F to 158°F
• Dimensions: 4-1/2"(L) x 3-1/4"(W) x 3/4"(D) inches
• Weight: 5-3/4 oz
• IP Rating: Indoor & Outdoor

Compatibility

• Compatible with HID® proximity cards using 26-Bit Wiegand format

The Transmitter Solutions DOLMGK-H delivers reliable Wiegand-based card and keypad access control in a compact single gang form factor.
