LiftMaster CSL24UL 24V DC Commercial Slide Gate Opener

LiftMaster CSL24UL Slide Gate Opener - Strength, Security, and Convenience

The LiftMaster CSL24UL Slide Gate Opener is built for tough environments like commercial and high-traffic residential areas. It features a powerful 24VDC motor that easily handles gates up to 1,500 lbs. and 50 feet in length. You can count on it for reliable performance every time, whether for a business or a gated community.

Key Features

• Heavy-Duty Performance: Designed for continuous use, this operator is ideal for high-cycle applications and demanding environments.
• Advanced Security: Security+ 2.0® technology provides encrypted communication for secure access control.
• Smart Connectivity: myQ® technology allows remote monitoring and control 828LM Internet Gateway (required, sold separately).
• Quick Close Feature: Automatically closes the gate quickly after entry or exit to enhance site security.
• Battery Backup: Provides up to 208 cycles during power outages for uninterrupted operation.
• Solar-Ready: Compatible with solar applications for flexible installation where power is limited.

Included Accessories

• LMRRUL Monitored Retro-Reflective Photo Eye
• S505AL Small Profile Edge
• 30 ft. of #41 Black Oxide Chain

Note: The included safety edge requires the LMWEKITU Wireless Edge Kit for operation.

Power & System Details

• Power Input: 120/230V single-phase
• Optional Kit: 3PHCONV converts 208/230/460/575VAC to 120VAC
• Accessory Power: 24VDC 500mA output (switched and un-switched)
• System Type: Solar-ready ultra-reliable system

Technical Specifications

• Motor: 24VDC
• Maximum Gate Size: 50 ft.
• Maximum Gate Weight: 1,500 lbs.

Dimensions

• Height: 25.07"
• Width: 15.55"
• Depth: 19.51"

The LiftMaster CSL24UL delivers a powerful combination of durability, smart technology, and reliable performance, making it an excellent choice for commercial and high-traffic gate automation.
