DoorKing 9210-381 1HP Slide Gate Operator
DKO-9210-381 – Genuine DoorKing 9210 slide gate operator with 1 HP motor, 115 VAC single-phase power, and #60 chain compatibility.
The DKO-9210-381 is a genuine DoorKing 9210 vehicular slide gate operator designed for commercial and industrial gate automation applications. Engineered for reliability, this operator features a 1 HP continuous-duty motor and a 40:1 gear reduction system running in a continuous oil bath for smooth, consistent performance.
The Model 9210 is capable of operating slide gates up to 100 feet in length. Maximum gate weight is rated at 2000 lb when using #50 chain and up to 3000 lb when using #60 chain, assuming the gate is level, properly maintained, and equipped with correctly adjusted hardware.
This operator is set for a travel speed of approximately 1 ft/sec (10–12 inches per second). The unit is shipped with chain brackets and 20 feet of #60 chain for installation convenience.
Key Specifications:
• Motor: 1 HP continuous-duty
• Speed: 1 ft/sec
• Gear Reduction: 40:1, continuous oil bath
• Maximum Gate Length: 100 ft
• Maximum Gate Weight: 2000 lb (#50) / 3000 lb (#60)
• Voltage: 115 VAC
• Phase: Single-phase
• Chain Type: #60
• Class of Operation: III & IV
• Listings: ETL Listed
Safety Note: To comply with UL 325 safety standards, this operator requires Type B1 and/or Type B2 entrapment protection devices. Verify installation requirements before ordering.
