DoorKing 9210-382 1HP Slide Gate Operator 208V
DKO-9210-382 – Genuine DoorKing 9210 slide gate operator, 1 HP, 208 VAC single-phase, #50 chain.
The DKO-9210-382 is a genuine DoorKing 9210 vehicular slide gate operator designed for demanding commercial and industrial slide gate applications. This model features a 1 HP continuous-duty motor and a 40:1 gear reduction system operating in a continuous oil bath for enhanced durability and performance.
The operator is designed for gates up to 100 feet in length. Maximum gate weight is rated at 2000 lb using #50 chain, assuming proper gate condition and level installation.
Operating speed is factory set at approximately 1 ft/sec, providing efficient gate travel. The operator is shipped with chain brackets and 20 feet of chain for installation.
Key Specifications:
• Motor: 1 HP continuous-duty
• Speed: 1 ft/sec
• Gear Reduction: 40:1 oil bath
• Maximum Gate Length: 100 ft
• Maximum Gate Weight: 2000 lb (#50)
• Voltage: 208 VAC
• Phase: Single-phase
• Chain Type: #50
• Class of Operation: III & IV
• Listings: ETL Listed
UL 325 compliant entrapment protection devices are required. Verify compatibility before ordering.
