LiftMaster RSL12UL 12V DC Residential Slide Gate Operator
The LiftMaster RSL12UL is a DC-powered slide gate operator with integrated battery backup, supporting gates up to 25 ft or 800 lbs for residential applications.
LiftMaster RSL12UL Slide Gate Operator
Your Smart Solution for Reliable Gate Automation
Meet the LiftMaster RSL12UL, a powerful and dependable DC-powered slide gate operator designed specifically for residential applications. This operator features an integrated battery backup system, keeping your gate operational even during power outages.
Built with a heavy-duty steel frame and weather-resistant components, the RSL12UL is engineered for long-lasting performance in a variety of environments. Smart control via MyQ® is available when paired with the optional 828LM Internet Gateway, allowing you to monitor and control your gate from anywhere.
Key Features
- Battery Backup Included: Keeps your gate operational during power outages.
- Optional Smart Control: MyQ® capability available with the addition of the 828LM Internet Gateway.
- Included Safety Devices: Comes with a 5 ft. small profile safety edge and LMRRUL reflective photo eye for UL 325 compliant protection.
- Chain Included: Includes 30 ft. of #41 black oxide chain for standard installations.
- Solar Ready: Compatible with solar power setups for off-grid applications.
Additional Requirements
- Wireless Edge Kit Required: The included safety edge requires the LM-WEKITU Wireless Edge Kit for proper operation if you are not hardwiring the connection. This item is not included and must be purchased separately.
- Solar Option (Sold Separately): For solar applications, the LM-20W33A 33AH 12V Solar Kit is recommended.
Technical Specifications
- Gate Capacity: Up to 25 ft. or 800 lbs.
- Power Supply: 120VAC input / 12VDC system
- Operating Temperature Range: -4°F to 140°F (-40°F to 140°F with heater)
