Siren Operated Sensor with Remote (SOS-12RM)
The Siren Operated Sensor 12RM pairs the SOS-12 sensor with a remote microphone, allowing the sensor to be placed up to 50 feet away while the mic captures siren signals for automatic gate access.
Overview
The Siren Operated Sensor 12RM combines the SOS-12 Siren Operated Sensor with a remote microphone, giving installers the flexibility to mount the sensor out of sight — in a guard shack or any remote location — while the microphone is positioned up to 50 feet away for reliable siren detection. When an emergency vehicle siren is recognized, the system triggers automatic gate access without the need for codes or keys. Trusted since 1992 and used across North, South, and Central America as well as Europe.
Key Features
- NEMA 4 enclosure — designed to go unnoticed
- Larger internal gaskets for enhanced protection
- Up-front microphone for faster detection
- Remote microphone placeable up to 50 feet from the SOS-12
- Adjustable sensitivity via potentiometer dial
- Four programming switches to customize trigger sound and gate-open duration
- Two reset buttons — one on the exterior enclosure, one on the interior circuit board
- 5-year warranty
- Compatible with all gate operators
- Includes reflective sign (choice of 4" x 5" or 8" x 10") to alert emergency responders
- Includes a CD recording of an emergency responder "yelp" siren for testing and sensitivity adjustment
Specifications
- Voltage: DC 9 to 30 volts or AC 9 to 16 volts
- Amp Draw: 0.1 mA when listening; 25 mA during trigger activation
- Wire Gauge: 18–22 AWG (not included)
- Operating Temperature: -30°F to 120°F
- Sensitivity Settings:
- Set at 0: will not trigger at any decibel level
- Set at 3: triggers at 125 decibels
- Set at 5: triggers at 105 decibels
- Set at 7: triggers at 95 decibels
- Set at 9: triggers at 80 decibels
- Gate-open duration options: single vehicle entry, hold open 15 minutes, or latch open until reset button is pushed
Compatibility
Compatible with all gate operators.
What's Included
- SOS-12 Siren Operated Sensor
- SOS Remote Microphone
- Reflective sign
The Siren Operated Sensor 12RM delivers proven emergency access performance with the added installation flexibility of a remote microphone.
