SPRING CONNECTING LINK BOLT - 3/4"

Overview

The All-O-Matic 26-5 is a 3/4" Spring Connecting Link Bolt, part of the jamb track hardware system for California Lift Gates. This component is used within a hardware range engineered for vehicular doors and gates.

Important Safety Notice

• This hardware is intended for vehicular doors and gates and must be inspected monthly for wear and lubricated as needed.
• Only a qualified service person should work on gate hardware.
• Springs are under tension. Do not attempt to adjust or change springs unless you are a service professional — improper handling can cause serious injury or death.

Compatible Hardware Sets

This bolt is part of an All-O-Matic jamb track hardware system available in the following configurations:

• Regular Short Set: 350 lbs, 19' width, 6'6"–7' height
• Regular Long Set: 350 lbs, 19' width, 7'–7'6" height
• Jumbo: 450 lbs, 20' width, 7'–8' height
• Heavy Jumbo: 550 lbs, 22' width, 7'–8' height
• Heavy Jumbo Long: 650 lbs, 22' width, 8'–10'6" height

Ensure you select the correct hardware configuration for your gate size and opening before installation.
