Viking Access Systems VASPSL3H10NX SPS Assembly Sensor

Digital Limit Sensor for Viking Access Slide Gate Operators

The Viking Access Systems VASPSL3H10NX is the primary digital limit sensor used in Viking Access L-3 and H-10 slide gate operators, including NX variants. It enables smart positioning logic by digitally detecting the gate's open and close positions, eliminating the need for mechanical limit switches. The sensor communicates directly with the operator's control board to set and maintain accurate travel limits.

Key Features

• Smart Limit Control — Enables digital limit detection for L-3 and H-10 slide gate operators
• Direct Communication — Integrates with Viking Access control boards to set and maintain travel limits
• No Mechanical Switches Required — Reduces wear and simplifies installation and calibration
• Model-Specific Part — For use only with operators that support the digital sensor system
• Plugs directly into the main control board
• Mounts inside the internal operator housing

Specifications

• Part Number: VASPSL3H10NX
• Sensor Type: Digital limit positioning sensor
• Mounting Type: Bolt-On / Plug-In, internal operator housing
• Application: Gate
• Installation Type: Residential and Commercial

Compatibility

• Viking Access H-10 slide gate operators
• Viking Access L-3 slide gate operators (including NX variants)

Verify firmware compatibility with your operator manual before installation. Replaces part number SPS ASSEMBLY L3/H10NX.
