Transmitter Solutions SR33HDB Battery Mini Vandal Resistant

Overview

The Transmitter Solutions SR33HDB iGaze is a 33-foot battery powered photoeye designed for anti-vandal industrial use. It operates on 12/24 VAC/DC and is powered by 6V via 4 AAA batteries on the transmitter side. With IP55 protection and a double rubber seal, it is built to withstand demanding environments.

Key Features

• Infrared send/receive photoeye
• Adjustable optics: +/- 90° horizontally and +/- 15° vertically
• IP55 protection rating
• Double rubber seal
• Anti-vandal construction for industrial use
• Compatible with N.C. & 10K gate operators
• UL listed
• Two range settings: 26 feet (Low) and 49 feet (High)
• Battery life: 24 months (low power) / 14 months (high power)

Specifications

• Power Supply: 12/24 VAC/DC
• TX Battery Type: 6V, 4 AAA
• Operating Temperature: 5° to 140°F
• Wave Length: 950 nm
• Modulation: 1.33 KHz
• Current Commutable by Relay: 1 A at 24 V
• RC Consumption at 12 VAC: 47 mA active; 35 mA inactive
• RC Consumption at 12 VDC: 22 mA active; 16 mA inactive
• RC Consumption at 24 VAC: 48 mA active; 36 mA inactive
• RC Consumption at 24 VDC: 24 mA active; 18 mA inactive
• Range: 26 feet (Low) / 49 feet (High)
• Battery Life (Low Power): 24 months
• Battery Life (High Power): 14 months

Compatibility

• Works with N.C. & 10K gate operators

The Transmitter Solutions SR33HDB delivers reliable infrared detection with industrial-grade vandal resistance and flexible power options for gate access applications.
