Transmitter Solutions RAY318LIPW2-V Visor Transmitter
SKU
ts-ray318lipw2-v
The Transmitter Solutions RAY318LIPW2-V is a 318 MHz two-button visor transmitter compatible with Linear® MCT-2 / MDT-2 systems, designed for access control and telephone entry applications.
Overview
The Transmitter Solutions RAY318LIPW2-V (Stingray 2) is a 318 MHz visor transmitter engineered for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems. It is directly compatible with the Linear® MCT-2 and MDT-2.
Key Features
- 318 MHz operating frequency
- Two-button (Blue) visor form factor
- Compatible with Linear® MCT-2 / MDT-2
- Programmable operation
- 5-year warranty
Specifications
- Supply: 1 Alkaline Battery, 12V type 23A
- Battery Life: 12–18 months
- Current Consumption: 20 mA
- Code Combinations: 65,536
- Facility Codes: 16
- Modulation: AM / ASK
- Range (free space): 60–120 yd
- Operating Temperature: -20 ÷ +55 °C
- Dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 1 oz. (20 gr.)
Compatibility
- Linear® MCT-2
- Linear® MDT-2
Replaces part number 318LIPW2V. Also available in a 1-button version (318LIPW1V).
