Transmitter Solutions RAY318DOPW1V Visor Transmitter

Overview

The Transmitter Solutions® Stingray RAY318DOPW1V is a programmable visor transmitter operating at 318 MHz. Designed for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems with a 318 MHz input.

Key Features

• Frequency: 318 MHz
• One Button (Red)
• Visor model design
• Compatible with DoorKing® MicroCLIK® 8066-080
• Programmable
• 5-Year Warranty

Specifications

• Supply: 1 Alkaline Battery, 12V type 23A
• Battery Life: 12–18 months
• Current Consumption: 20 mA
• Code Combinations: 16,384
• Facility Codes: 64
• Modulation: AM / ASK
• Range in Free Space: 60–120 yd
• Operating Temperature: -20 ÷ +55 °C
• Dimensions: 3.26 x 1.88 x 0.62 in
• Weight: 1 oz. (20 gr.)

Compatibility

• DoorKing® MicroCLIK® 8066-080

Also available in a 2-button version: model 318DOPW2V.
