Transmitter Solutions RAY318DOPW2V Visor Transmitter
SKU
ts-ray318dopw2v
The Transmitter Solutions RAY318DOPW2V is a 318 MHz two-button visor transmitter compatible with the DoorKing® MicroCLIK® 8067-080, designed for access control and telephone entry systems.
Overview
The Transmitter Solutions® RAY318DOPW2V is a programmable visor transmitter operating at 318 MHz. Designed for use with Wiegand 26-bit programmable telephone entry systems, anti-burglar systems, and access control systems, it offers reliable wireless operation and is compatible with the DoorKing® MicroCLIK® 8067-080.
Key Features
- 318 MHz operating frequency
- Two-button (Red) visor model
- Compatible with DoorKing® MicroCLIK® 8067-080
- Programmable
- 5-Year Warranty
Specifications
- Supply: 1 Alkaline Battery, 12V type 23A
- Battery Life: 12–18 months
- Current Consumption: 20 mA
- Code Combinations: 16,384
- Facility Codes: 64
- Modulation: AM / ASK
- Range in Free Space: 60–120 yd
- Operating Temperature: -20 ÷ +55 °C
- Overall Dimensions: 3.26 x 1.88 x 0.62 in
- Weight: 1 oz. (20 gr.)
Compatibility
- DoorKing® MicroCLIK® 8067-080
Also available in a one-button version: 318DOPW1V.
